ProductFeature
1.Overheating protectionª Overheating protectionªovervoltage protection
2.EMC protection
3.Leakage protectionª Grounding detection
4.The sign light indicate status
TechnicalParameters
| Standard | GBT20234.1, GBT20234.2, GBT18487.1 |
| Rated Voltage | 250V AC |
| Rated Current | AC: 6A / 10A / 13A / 16A |
| Temperature Range | -40℃ ~ +50℃ |
| Insulation Resistance | 1000VDC 1min > 500MΩ (Note: "mo" is a typo, should be MΩ) |
| Dielectric Withstanding Voltage | 2500VAC 1min, Leakage current ≤ 5mA (Note: "Insertion and Extraction Force" is incorrect terminology) |
| Mechanical Life | ≥ 10000 times |
| Degree of Protection | The lid or cap: IP54; Mating connector: IP54; Body: IP67 |
| Cable Length | 3M / 5M / 10M / 15M / 20M |
