Categories
| Categories | MCCB |
| Model | STM6 |
| Rated current(A) | 10-800A |
| Rated operating voltage(Ue) | 400V |
| Rated Insulation Voltage(Ui) | 1000V |
| Rated impact withstand voltage(Uimp) | 8kV |
| Product name | STM6 |
| Rated limit short circuit capacity | 50 |
| Rated operatingshort circuit capacity | 35 |
| Pole | 2P, 3p, 4p |
| website | www.sofielec.com |
| Brand | sofielec |
