Function
|
Astronomical time switch |
|
1 channel |
|
Latitude set North: 1 ~ 66º and South:1 ~ 66º (1º increased) |
|
Perpetual calendar (40 years) |
|
Program follows / non-follow the sunrise / sunset |
|
Program follows / non-follows the change in Daylight Saving Time |
|
Manually set Daylight Saving Time(1 Hours) |
|
8 ON / OFF program |
|
Preset date and time |
|
Switching preselection |
|
Fully operable without mains connection |
|
Built-in lithium battery,power failure memory |
|
12/24 hour format conversion |
|
Screw terminals |
|
Solar energy equipment |
|
Light of billboard or showcase control |
|
Pumps/Motor/Fan Control |
|
Hydroponic Systems |
|
Wastewater Treatment Systems |
|
Boilers / Heater Control |
|
Pool & Spa |
|
Lighting Panel Control |
|
Landscape Lighting |
|
Bug and Pest Control Systems |
|
Aerobic Waste Water Systems |
|
General Electrical Circuits |
Product Selection
|
Product Type |
Voltage |
Frequency |
Terminal |
Switching capacity |
|
AHC15T-220/50Hz-16A |
220V |
50Hz |
5
|
16A |
|
AHC15T-220/60Hz-16A |
60Hz |
|||
|
AHC15T-110/50Hz-16A
|
110V |
50Hz |
||
|
AHC15T-110/60Hz-16A |
60Hz |
|||
|
AHC15T-12V-16A |
AC/DC 12V |
50/60Hz for AC |
||
|
AHC15T-24V-16A
|
AC/DC 24V |
|||
|
AHC15T-220/50Hz-3P-20A |
220V |
50Hz |
3
|
20A |
|
AHC15T-220/50Hz-5P-20A |
5
|
|||
|
AHC15T-220/60Hz-3P-2 |
50Hz |
3
|
||
|
AHC15T-220/60Hz-5P-20A
|
5
|
|||
|
AHC15T-110/50Hz-3P-20A |
110V |
60Hz |
3
|
20A |
|
AHC15T-110/50Hz-5P-20A |
5
|
|||
|
AHC15T-110/60Hz-3P-20A |
60Hz
|
3
|
||
|
AHC15T-110/60Hz-5P-20A |
5
|
|||
|
AHC812-12V |
AC/DC 12V |
AC 50/60Hz |
5
|
|
|
AHC812-24V |
AC/DC 24V |
AC 50/60Hz |
5
|
Technical Data
|
Product Type |
AHC15T |
|
Number of ON / OFF programs |
20 |
|
Width |
2 modules |
|
Type of contactInstallation type
|
Din rail |
|
Type of contact |
Changeover contact
|
|
Switching output |
Phase-independent |
|
Method of connection terminal
|
Screw terminals |
|
Power reserve |
3 years |
|
Switching capacity at 250 V AC, cos φ = 1 |
16A |
|
Switching capacity at 250 V AC, cos φ = 0,6 |
10A |
|
Energy saving lampsIncandescent/halogen lamp load 230V
|
2600W |
|
Energy saving lamps |
170W |
|
LED lamp < 2 W |
30W |
|
LED lamp 2–8 W |
100W |
|
LED lamp > 8 W |
120W |
|
Fluorescent lamp load (electronic ballast) |
650W |
|
Fluorescent lamp load (conventional) not corrected |
1000VA |
|
|
